GLF24200-01 25.6V 200Ah Lithium Battery Pack with BMS Parallel Capable
Features
Easy Installation
- Modular design
- DIY-friendly
- Supports up to 6 units in parallel
Safety and Reliability
- Wide temperature range
- LiFePO₄ chemistry
- IP65 grade
Smart O&M
- RS485 & CAN communication
- Remote diagnostics & upgrades
- Auto protection: overcharge, over-discharge, overheating, cell imbalance
SPECIFICATION
GLF24200-01 25.6V 200Ah Lithium Battery Pack with BMS Parallel Capable supports RS485, CAN, and RS232 communication protocols, offers excellent safety, over 6000 cycles of lifespan, and allows up to 6 units in parallel, delivering stable and reliable green energy for off-grid systems, solar PV, and backup power applications.
| Product Parameter | |
| Model | GLF24200-01 |
| Battery Type | LiFePO4 |
| Nominal Voltage | 25.6V |
| Nominal Capacity | 200Ah |
| Charging Cut-off Voltage | 29.2V |
| Discharging Cut-off Voltage | 20V |
| Max. Cont. Charging/Discharging Current (30s) | 200A |
| Continuous Charge/Discharge Current | 80A |
| Max. Number Of Parallel | 6 sets |
| Cycle Life | ≥6000 |
| Product Size | 635*456*156mm |
| Weight | 51kg |
| Warranty | 5 years |
Panel Indication
