STM 8.2kW/10.6kW Hybrid Pure Sine Wave Solar Inverter with MPPT and Dual AC Output
Features
High Yields
- 1.0 power factor
- Dual MPPT, 90–500VDC PV input range
Flexible and Reliable
- Built-in 160A/180A MPPT solar charger
- Lithium battery auto-activation circuit
- 4 configurable charging modes & 3 output priority modes
User Friendly
- WiFi & GPRS monitoring via iOS / Android App
- RGB mode indicator + LED display
SPECIFICATION
STM 8.2kW/10.6kW Hybrid Pure Sine Wave Solar Inverter with dual MPPT, dual AC output, WiFi/GPRS monitoring, and battery-free operation—ideal for home, RV, and off-grid solar systems.
| Product Parameter | ||
| Model | STM82248 | STM102248 |
| Rated Output Power | 8200W | 10200W |
| Maximum PV Array Open Circuit Voltage | 500VDC | 360VDC |
| MPPT Operating Voltage | 90~450VDC | 90~450VDC |
| Full Load MPPT Operating Voltage | 360~450VDC | 360~450VDC |
| Number Of MPPT/Maximum Input Current | 1/27A | 1/27A |
| Maximum PV Charging Current | 160A | 160A |
| Feed-In Grid Voltage | 230VAC, 50/60Hz | 230VAC, 50/60Hz |
| Nominal Output Voltage | 230VAC, 50/60Hz | 230VAC, 50/60Hz |
| Maximum Main Load | 8200W | 10200W |
| Maximum Second Load | 2733W | 3400W |
| Main Load Cut Off/Return Voltage | 44V/52VDC | 44V/52VDC |
| Nominal Input Voltage | 230VAC, 50/60Hz | 230VAC, 50/60Hz |
| Maximum AC Charging Current | 140A | 140A |
| Battery Voltage | 48VDC | 48VDC |
| Communication Port | RS232/GPRS/WIFI | RS232/GPRS/WIFI |
| Product Size | 390x530x130mm | 390x530x130mm |
| Weight | 14.2kg | 14.5kg |
| Warranty | 3 years | 3 years |
Product detail
