STN 1kW-3kW Pure Sine Wave Hybrid Solar Inverter
Features
Reliability & Safety
- UPS function, 10ms transition
- Output power factor 1.0
- Pure sine wave output
High Yields
- Maximum PV Charging Current up to 80A
- Wide PV input range up to 400VDC
Smart & Flexible
- Wi-Fi & GPRS monitoring
- Supports lithium & lead-acid batteries
- Compact, dust-proof design
SPECIFICATION
STN 1kW-3kW Pure Sine Wave Hybrid Solar Inverter integrates solar and battery charging with high-efficiency MPPT, dust-proof design, and smart management, supporting various battery types and delivering reliable, uninterrupted power for home and office applications.
| Product Parameter | ||||
| Model | STN10212 | STN15224 | STN20212 | STN30224 |
| Rated Power | 1000VA/1000W | 1500VA/1500W | 2000VA/2000W | 3200VA/3000W |
| Surge Power | 2000VA | 3000VA | 4000VA | 6400VA |
| AC Input Voltage | 230VAC | 230VAC | 230VAC | 230VAC |
| Frequency Range | 50Hz/60Hz(Auto Sensing) | 50/60Hz | 50/60Hz | 50/60Hz |
| AC Output Voltage | 230VAC | 230VAC | 230VAC | 230VAC |
| Efficiency(Peak)PV To INV | 98% | 98% | 98% | 98% |
| Efficiency(Peak)Battery To INV | 94% | 94% | 94% | 94% |
| Maximum AC Charging Current | 40A | 40A | 60A | 60A |
| Battery Voltage | 12VDC | 24VDC | 12VDC | 24VDC |
| Maximum PV Array Power | 600W | 1200W | 2000W | 3000W |
| Maximum PV Array Open Voltage | 150VDC | 150VDC | 400VDC | 400VDC |
| MPPT Operating Voltage Range | 20~150VDC | 30~120VDC | 30~400VDC | 240~350VDC（Full Load） |
| Maximum PV Charging Current | 40A | 40A | 80A | 80A |
| Operating Temperature | -10~50°C | -10~50°C | -10~50°C | -10~50°C |
| Communication Interface | RS232/GPRS/WIFI | RS232/GPRS/WIFI | RS232/GPRS/WIFI | RS232/GPRS/WIFI |
| Product Size | 240x290x91mm | 290x240x91mm | 273x357x95mm | 273*357*95mm |
| Weight | 3.5kg | 3.6kg | 5.2kg | 6.2kg |
| Warranty | 3 years | 3 years | 3 years | 3 years |
Product detail
